| General information |
|---|
| Model: | Yamaha XV 535 |
| Year: | 1993 |
| Category: | Unspecified category |
| Rating: | 71.5 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 535.00 ccm (32.65 cubic inches) |
| Engine type: | V2 |
| Stroke: | 4 |
| Power: | 46.00 HP (33.6 kW)) @ 7500 RPM |
| Torque: | 47.07 Nm (4.8 kgf-m or 34.7 ft.lbs) @ 6000 RPM |
| Valves per cylinder: | 2 |
| Gearbox: | 5-speed |
| More details | Consult a Yamaha repair manual. |
| Physical measures |
|---|
| Dry weight: | 182.0 kg (401.2 pounds) |
| Seat height: | 700 mm (27.6 inches) If adjustable, lowest setting. |
| Chassis and dimensions |
|---|
| Front brakes: | Single disc |
| Rear brakes: | Expanding brake |
| Speed and acceleration |
|---|
| Power/weight ratio: | 0.2527 HP/kg |
| Other specifications |
|---|
| Fuel capacity: | 13.50 litres (3.57 gallons) |
| Reserve fuel capacity: | 2.00 litres (0.53 gallons) |
