| Yamaha's profilation of this bike |
| Borrowing liberally from advanced sportbike technology, VMAX features a slipper clutch, wave-style brake discs, ABS, and complete suspension adjustability front and rear. Functionality and forward-thinking style uniquely combine with features like oxidized-titanium-coated 52mm front fork tubes, magnesium engine side covers, fluorinated polyethylene fuel tank and the organic electroluminescence multifunction display. |
| General information |
|---|
| Model: | Yamaha VMAX | | Year: | 2013 | | Category: | Custom / cruiser | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Price as new (MSRP): | US$ 19990. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 1671.58 ccm (102.00 cubic inches) | | Engine type: | V4, four-stroke | | Engine details: | 65° V-4 | | Compression: | 11.3:1 | | Bore x stroke: | 90.0 x 66.0 mm (3.5 x 2.6 inches) | | Valves per cylinder: | 4 | | Fuel system: | Injection. Fuel Injection with YCC-T and YCC-I | | Fuel control: | DOHC | | Ignition: | TCI: Transistor Controlled Ignition | | Cooling system: | Liquid | | Gearbox: | 5-speed | Transmission type,
final drive: | Shaft drive (cardan) | | Fuel consumption: | 8.71 litres/100 km (11.5 km/l or 27.01 mpg) | | Greenhouse gases: | 202.1 CO2 g/km. (CO2 - Carbon dioxide emission) | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Aluminum | | Rake (fork angle): | 31.0° | | Trail: | 147 mm (5.8 inches) | | Front suspension: | 52mm telescopic cartridge fork w/oxidized titanium coating. Fully adjustable preload, compression and rebound | | Front suspension travel: | 119 mm (4.7 inches) | | Rear suspension: | Single shock w/remote reservoir and remote adjustable for preload, compression and rebound | | Front tyre dimensions: | 120/70-18 | | Rear tyre dimensions: | 200/50-18 | | Front brakes: | Double disc. ABS. Six-piston calipers. Radially mounted. | | Front brakes diameter: | 320 mm (12.6 inches) | | Rear brakes: | Single disc. ABS. Single-piston caliper. | | Rear brakes diameter: | 298 mm (11.7 inches) | | Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 309.8 kg (683.0 pounds) | | Seat height: | 775 mm (30.5 inches) If adjustable, lowest setting. | | Overall height: | 1,191 mm (46.9 inches) | | Overall length: | 2,395 mm (94.3 inches) | | Overall width: | 820 mm (32.3 inches) | | Wheelbase: | 1,699 mm (66.9 inches) | | Fuel capacity: | 15.14 litres (4.00 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Factory warranty: | 12 months limited factory warranty. | | Color options: | Nebulous Purple | | Further information |
|---|
