| Yamaha's profilation of this bike |
| Aggressive Raptor style and stance gives maximum performance and excellent, all-day sport-riding ergonomics. Class-exclusive five-speed manual transmission has a gear for almost any terrain. |
| General information |
|---|
| Model: | Yamaha Raptor 250 | | Year: | 2011 | | Category: | ATV | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Price as new (MSRP): | US$ 4599. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 249.00 ccm (15.19 cubic inches) | | Engine type: | Single cylinder, four-stroke | | Compression: | 9.5:1 | | Bore x stroke: | 74.0 x 58.0 mm (2.9 x 2.3 inches) | | Valves per cylinder: | 2 | | Fuel system: | Carburettor. Mikuni 29mm BSR | | Fuel control: | SOHC | | Ignition: | DC-CDI | | Cooling system: | Oil & air | | Gearbox: | 5-speed | Transmission type,
final drive: | Chain | | Driveline: | 2WD; sealed O-ring chain, eccentric adjustment | | Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Independent double wishbone | | Front suspension travel: | 127 mm (5.0 inches) | | Rear suspension: | Swingarm, preload-adjustable, 7.9-in travel | | Front tyre dimensions: | 20/7-10 | | Rear tyre dimensions: | 19/10-9 | | Front brakes: | Double disc | | Rear brakes: | Single disc | | Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 149.7 kg (330.0 pounds) | | Seat height: | 729 mm (28.7 inches) If adjustable, lowest setting. | | Overall height: | 1,039 mm (40.9 inches) | | Overall length: | 1,626 mm (64.0 inches) | | Overall width: | 1,069 mm (42.1 inches) | | Ground clearance: | 99 mm (3.9 inches) | | Wheelbase: | 1,110 mm (43.7 inches) | | Fuel capacity: | 9.08 litres (2.40 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Light: | Dual 30W Krypton multireflector headlights and 21/5W brakelight | | Factory warranty: | 6 Month (Limited Factory Warranty) | | Color options: | Team Yamaha Blue/White, White w/Graphics Kit | | Further information |
|---|
