| Yamaha's profilation of this bike |
| Pure functionality with a cool, understated look that’s as comfortable outside a 5-star hotel as it is on the beach: that’s the BW Next Generation. |
| General moped information |
|---|
| Model: | Yamaha BWs Next Generation | | Year: | 2008 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Engine and transmission |
|---|
| Displacement: | 49.20 ccm (3.00 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 2 | | Power: | 3.62 HP (2.6 kW)) @ 6800 RPM | | Torque: | 4.00 Nm (0.4 kgf-m or 3.0 ft.lbs) @ 5000 RPM | | Compression: | 11.2:1 | | Bore x stroke: | 40.0 x 39.2 mm (1.6 x 1.5 inches) | | Ignition: | CDI | | Starter: | Electric & kick | | Lubrication system: | Separate lubrication | | Cooling system: | Air | Transmission type
final drive: | Belt | | More details | Consult a Yamaha repair manual. | | Physical measures |
|---|
| Dry weight: | 77.0 kg (169.8 pounds) | | Seat height: | 803 mm (31.6 inches) If adjustable, lowest setting. | | Overall height: | 1,120 mm (44.1 inches) | | Overall length: | 1,746 mm (68.7 inches) | | Overall width: | 675 mm (26.6 inches) | | Ground clearance: | 153 mm (6.0 inches) | | Chassis and dimensions |
|---|
| Frame type: | - | | Front suspension: | Hydraulic and telescopic fork | | Rear suspension: | Hydraulic unit swing | | Front tyre dimensions: | 120/90-10 | | Rear tyre dimensions: | 130/90-10 | | Front brakes: | Single disc | | Front brakes diameter: | 190 mm (7.5 inches) | | Rear brakes: | Expanding brake (drum brake) | | Rear brakes diameter: | 110 mm (4.3 inches) | | Speed and acceleration |
|---|
| Power/weight ratio: | 0.0470 HP/kg | | Other specifications |
|---|
| Fuel capacity: | 6.50 litres (1.72 gallons) | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our partners.  |
| Ask questions | Join the 08 Yamaha BWs Next Generation discussion group,
the new Yamaha forum at Bikez.name or
the new Scooter forum at Bikez.name. |
| Insurance, loans, tests
| Search the web for dealers, loan and insurance costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
