| Yamaha's profilation of this bike |
| BW´s 12inch brings the added stability of 12inch wheels and the assured suppleness of high-performance remote-reservoir suspension to the classic BW’s package. |
| General moped information |
|---|
| Model: | Yamaha BWs 12inch | | Year: | 2008 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Engine and transmission |
|---|
| Displacement: | 49.20 ccm (3.00 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 2 | | Power: | 3.21 HP (2.3 kW)) @ 6500 RPM | | Torque: | 3.60 Nm (0.4 kgf-m or 2.7 ft.lbs) @ 6000 RPM | | Compression: | 7.2:1 | | Bore x stroke: | 40.0 x 39.2 mm (1.6 x 1.5 inches) | | Ignition: | CDI | | Starter: | Electric & kick | | Lubrication system: | Wet sump | | Cooling system: | Air | | More details | Consult a Yamaha repair manual. | | Physical measures |
|---|
| Dry weight: | 75.0 kg (165.3 pounds) | | Seat height: | 768 mm (30.2 inches) If adjustable, lowest setting. | | Overall height: | 1,052 mm (41.4 inches) | | Overall length: | 1,685 mm (66.3 inches) | | Overall width: | 690 mm (27.2 inches) | | Ground clearance: | 124 mm (4.9 inches) | | Wheelbase: | 1,172 mm (46.1 inches) | | Chassis and dimensions |
|---|
| Frame type: | - | | Front suspension: | Hydraulic and telescopic fork | | Rear suspension: | Hydraulic unit swing | | Front tyre dimensions: | 120/70-12 | | Rear tyre dimensions: | 130/70-12 | | Front brakes: | Single disc | | Front brakes diameter: | 180 mm (7.1 inches) | | Rear brakes: | Expanding brake (drum brake) | | Rear brakes diameter: | 110 mm (4.3 inches) | | Speed and acceleration |
|---|
| Power/weight ratio: | 0.0428 HP/kg | | Other specifications |
|---|
| Fuel capacity: | 5.30 litres (1.40 gallons) | | Further information |
|---|
