| General information |
|---|
| Model: | Suzuki Marauder 125 |
| Year: | 2006 |
| Category: | Custom / cruiser |
| Rating: | 74.7 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 125.00 ccm (7.63 cubic inches) |
| Engine type: | Single cylinder |
| Stroke: | 4 |
| Power: | 11.53 HP (8.4 kW)) @ 9000 RPM |
| Torque: | 9.60 Nm (1.0 kgf-m or 7.1 ft.lbs) @ 7000 RPM |
| Compression: | 9.5:1 |
| Bore x stroke: | 57.0 x 48.8 mm (2.2 x 1.9 inches) |
| Fuel system: | Carburettor. Mikuni BS26 SS |
| Fuel control: | SOHC |
| Ignition: | Electronic |
| Starter: | Electric |
| Lubrication system: | Wet sump |
| Cooling system: | Air |
| Gearbox: | 5-speed |
Transmission type
final drive: | Chain |
| Clutch: | Wet multi plate |
| More details | Consult a Suzuki repair manual. |
| Physical measures |
|---|
| Dry weight: | 241.0 kg (531.3 pounds) |
| Seat height: | 680 mm (26.8 inches) If adjustable, lowest setting. |
| Alternate seat height: | 805 mm (31.7 inches) If adjustable, highest setting. |
| Overall height: | 1,090 mm (42.9 inches) |
| Overall length: | 2,160 mm (85.0 inches) |
| Overall width: | 815 mm (32.1 inches) |
| Ground clearance: | 140 mm (5.5 inches) |
| Wheelbase: | 1,450 mm (57.1 inches) |
| Chassis and dimensions |
|---|
| Rake (fork angle): | 32.5° |
| Front suspension: | Telescopic |
| Rear suspension: | Twin shock absorber, adjustable spring preload |
| Front brakes: | Single disc |
| Front brakes diameter: | 275 mm (10.8 inches) |
| Rear brakes: | Expanding brake (drum brake) |
| Rear brakes diameter: | 130 mm (5.1 inches) |
| Speed and acceleration |
|---|
| Power/weight ratio: | 0.0478 HP/kg |
| Other specifications |
|---|
| Fuel capacity: | 13.00 litres (3.43 gallons) |
