| General information |
|---|
| Model: | Saxon Javelin |
| Year: | 2009 |
| Category: | Custom / cruiser |
| Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 1573.00 ccm (95.98 cubic inches) |
| Engine type: | V2 |
| Stroke: | 4 |
| Compression: | 10.1:1 |
| Bore x stroke: | 94.0 x 116.8 mm (3.7 x 4.6 inches) |
| Fuel system: | Carburettor. S and S Super E |
| Fuel control: | OHV |
| Starter: | Electric |
| Gearbox: | 6-speed |
Transmission type
final drive: | Chain |
| Physical measures |
|---|
| Dry weight: | 300.3 kg (662.0 pounds) |
| Seat height: | 660 mm (26.0 inches) If adjustable, lowest setting. |
| Chassis and dimensions |
|---|
| Frame type: | Stretch 0 In Downtube - 4 In Backbone |
| Rake (fork angle): | 40.0° |
| Front suspension: | 41 mm Telescopic 4 In Over |
| Rear suspension: | Hidden Progressive Shocks |
| Front tyre dimensions: | 2.15-21 |
| Rear tyre dimensions: | 300-18 |
| Front brakes: | Single disc. Bremo 4-piston calipers |
| Rear brakes: | Single disc. Bremo 2- piston calipers |
| Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 13.24 litres (3.50 gallons) |
| Oil capacity: | 3.30 litres (0.22 quarts) |
