| General information |
|---|
| Model: | Saxon Crown |
| Year: | 2009 |
| Category: | Custom / cruiser |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 1573.00 ccm (95.98 cubic inches) |
| Engine type: | V2 |
| Stroke: | 4 |
| Compression: | 10.1:1 |
| Bore x stroke: | 94.0 x 116.8 mm (3.7 x 4.6 inches) |
| Fuel system: | Carburettor. S and S Super E Carburator |
| Fuel control: | OHV |
| Starter: | Electric |
| Gearbox: | 6-speed |
Transmission type
final drive: | Belt |
| Physical measures |
|---|
| Dry weight: | 283.5 kg (625.0 pounds) |
| Seat height: | 635 mm (25.0 inches) If adjustable, lowest setting. |
| Chassis and dimensions |
|---|
| Frame type: | Stretch 6 In Downtube - 2 In Backbone |
| Rake (fork angle): | 34.0° |
| Front suspension: | Springer 4´´ over |
| Rear suspension: | Hidden Progressive Shocks |
| Front tyre dimensions: | 2.15-21 |
| Rear tyre dimensions: | 240-18 |
| Front brakes: | Single disc. Bremo 4-piston calipers |
| Rear brakes: | Single disc. Bremo 2- piston calipers |
| Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 11.35 litres (3.00 gallons) |
| Fuel consumption pr. 10 km (6.2 miles): | 67.20 litres (17.75 gallons) |
| Oil capacity: | 3.30 litres (0.22 quarts) |
| Color options: | Custom |
