| General information |
|---|
| Model: | Pitster Pro MX 110R |
| Year: | 2012 |
| Category: | Minibike, cross |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Price as new (MSRP): | US$ 1999. Prices depend on country, taxes, accessories, etc. |
| Engine and transmission |
|---|
| Displacement: | 110.00 ccm (6.71 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Compression: | 9.2:1 |
| Bore x stroke: | 52.5 x 49.5 mm (2.1 x 1.9 inches) |
| Fuel system: | Carburettor |
| Fuel control: | SOHC |
| Ignition: | Stator/ CDI with lighting coil |
| Cooling system: | Air |
| Gearbox: | 4-speed |
Transmission type,
final drive: | Chain |
| Clutch: | 5 plate wet clutch |
| Exhaust system: | FMF Factory 4.1 |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Central Double Cradle Chromo W/ Tri Point Mounting, removable footpeg Design, Progressive Link |
| Front suspension: | GPX Moto forks w/ Separate Comp and Reb Adjustment |
| Rear suspension: | Pitster Progressive Link Swingarm w/ Comp. and Rebound Adjustment, Adjustable Spring Preload |
| Front tyre dimensions: | 2.75-14 |
| Rear tyre dimensions: | 1.85-12 |
| Front brakes: | Single disc. W-Style Rotor W/ Floating Caliper |
| Front brakes diameter: | 220 mm (8.7 inches) |
| Rear brakes: | Single disc. W-Style Rotor W/ Floating Caliper |
| Rear brakes diameter: | 190 mm (7.5 inches) |
| Wheels: | Standard |
| Physical measures and capacities |
|---|
| Dry weight: | 64.9 kg (143.0 pounds) |
| Seat height: | 31 mm (1.2 inches) If adjustable, lowest setting. |
| Ground clearance: | 254 mm (10.0 inches) |
| Wheelbase: | 1,161 mm (45.7 inches) |
| Fuel capacity: | 3.80 litres (1.00 gallons) |
| Other specifications |
|---|
| Starter: | Electric & kick |
| Color options: | White |
