| Moto Morini's profilation of this bike |
| Unadorned, eclectic, agile and easy to handle. Feel free again. |
| General information |
|---|
| Model: | Moto Morini Scrambler | | Year: | 2011 | | Category: | Enduro / offroad | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Price as new (MSRP): | Euro 12290. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 1187.00 ccm (72.43 cubic inches) | | Engine type: | V2, four-stroke | | Engine details: | 87 degree longitudinal | | Power: | 117.00 HP (85.4 kW)) @ 8500 RPM | | Torque: | 102.00 Nm (10.4 kgf-m or 75.2 ft.lbs) @ 6700 RPM | | Bore x stroke: | 107.0 x 66.0 mm (4.2 x 2.6 inches) | | Valves per cylinder: | 4 | | Fuel system: | Injection. Magneti Marelli | | Fuel control: | DOHC | | Ignition: | I.A.W. | | Cooling system: | Liquid | | Gearbox: | 6-speed | Transmission type,
final drive: | Chain | | Clutch: | Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder | | Emission details: | Euro III | | Exhaust system: | Double silencer, 3-way catalytic converter and oxygen sensor. | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Verlicchi high-strength steel tube trellis frame | | Rake (fork angle): | 26.5° | | Trail: | 120 mm (4.7 inches) | | Front suspension: | Marzocchi upside-down fully adjustable fork | | Front suspension travel: | 155 mm (6.1 inches) | | Rear suspension: | With progressive motion and single Sachs shock absorber adjustable in extension, compression and spring pre-charge with singlering-nut.Enhanced piston and stretched counter-spring | | Rear suspension travel: | 190 mm (7.5 inches) | | Front tyre dimensions: | 110/80-R17 | | Rear tyre dimensions: | 150/70-R17 | | Front brakes: | Single disc. 2-piston | | Front brakes diameter: | 298 mm (11.7 inches) | | Rear brakes: | Single disc | | Rear brakes diameter: | 250 mm (9.8 inches) | | Physical measures and capacities |
|---|
| Dry weight: | 198.0 kg (436.5 pounds) | | Power/weight ratio: | 0.5909 HP/kg | | Seat height: | 840 mm (33.1 inches) If adjustable, lowest setting. | | Overall length: | 2,180 mm (85.8 inches) | | Overall width: | 865 mm (34.1 inches) | | Ground clearance: | 162 mm (6.4 inches) | | Wheelbase: | 1,500 mm (59.1 inches) | | Fuel capacity: | 21.00 litres (5.55 gallons) | | Reserve fuel capacity: | 4.50 litres (1.19 gallons) | | Other specifications |
|---|
| Factory warranty: | 3 year unlimited milage | | Color options: | Black/white, red/white/black | | Comments: | Italian bike. | | Further information |
|---|
