| Moto Morini's profilation of this bike |
| The Corsaro is a road beast: the sound of itīs twin cylinder 140 HP becomes a part of you, and never letīs you go.
|
| General information |
|---|
| Model: | Moto Morini Corsaro 1200 | | Year: | 2010 | | Category: | Naked bike | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Engine and transmission |
|---|
| Displacement: | 1187.00 ccm (72.43 cubic inches) | | Engine type: | V2, four-stroke | | Power: | 140.00 HP (102.2 kW)) @ 8500 RPM | | Torque: | 123.00 Nm (12.5 kgf-m or 90.7 ft.lbs) @ 12500 RPM | | Compression: | 11.8:1 | | Bore x stroke: | 107.0 x 66.0 mm (4.2 x 2.6 inches) | | Valves per cylinder: | 4 | | Fuel system: | Injection. Magneti Marelli, 54 mm throttle body | | Fuel control: | DOHC | | Cooling system: | Liquid | | Gearbox: | 6-speed | Transmission type,
final drive: | Chain | | Clutch: | Multiple-plate clutch in oil bath with antiskipping system and radial master-cylinder | | Exhaust system: | Sport Termignoni with double silencer, 3-way catalytic converter and oxygen sensor. Euro 3. | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | High-strength steel tube trellis frame | | Rake (fork angle): | 24.5° | | Trail: | 103 mm (4.1 inches) | | Front suspension: | Marzocchi upside down with 50 mm/ 1.96 Ø | | Front suspension travel: | 129 mm (5.1 inches) | | Rear suspension: | Sachs shock absorber | | Rear suspension travel: | 130 mm (5.1 inches) | | Front tyre dimensions: | 120/70-R17 | | Rear tyre dimensions: | 180/55-R17 | | Front brakes: | Double disc. Bremo, 4-piston | | Front brakes diameter: | 320 mm (12.6 inches) | | Rear brakes: | Single disc. Bremo | | Rear brakes diameter: | 220 mm (8.7 inches) | | Physical measures and capacities |
|---|
| Dry weight: | 198.0 kg (436.5 pounds) | | Power/weight ratio: | 0.7071 HP/kg | | Seat height: | 830 mm (32.7 inches) If adjustable, lowest setting. | | Overall length: | 2,070 mm (81.5 inches) | | Overall width: | 810 mm (31.9 inches) | | Ground clearance: | 140 mm (5.5 inches) | | Wheelbase: | 1,440 mm (56.7 inches) | | Fuel capacity: | 18.00 litres (4.76 gallons) | | Reserve fuel capacity: | 4.00 litres (1.06 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Color options: | Black/grey, red/gray, white/black | | Further information |
|---|
