| General information |
|---|
| Model: | Malaguti Ciak Master 125 | | Year: | 2007 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Engine and transmission |
|---|
| Displacement: | 124.00 ccm (7.57 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 4 | | Torque: | 9.00 Nm (0.9 kgf-m or 6.6 ft.lbs) @ 6000 RPM | | Compression: | 9.6:1 | | Bore x stroke: | 52.4 x 57.8 mm (2.1 x 2.3 inches) | | Fuel system: | Carburettor | | Valves per cylinder: | 2 | | Fuel control: | SOHC | | Starter: | Electric & kick | | Cooling system: | Air | | Gearbox: | Automatic | Transmission type
final drive: | Belt | | Clutch: | Automatic centrifugal dry clutch | | Physical measures |
|---|
| Dry weight: | 117.0 kg (257.9 pounds) | | Seat height: | 770 mm (30.3 inches) If adjustable, lowest setting. | | Overall height: | 1,200 mm (47.2 inches) | | Overall length: | 2,020 mm (79.5 inches) | | Overall width: | 725 mm (28.5 inches) | | Wheelbase: | 1,380 mm (54.3 inches) | | Chassis and dimensions |
|---|
| Frame type: | Tubular steel frame split at the footboard level | | Front suspension: | Telescopic hydraulic fork | | Rear suspension: | Swinging engine and 2 hydraulic shock absorbers | | Front tyre dimensions: | 100/80-16 | | Rear tyre dimensions: | 110/80-16 | | Front brakes: | Single disc | | Front brakes diameter: | 230 mm (9.1 inches) | | Rear brakes: | Expanding brake (drum brake) | | Rear brakes diameter: | 130 mm (5.1 inches) | | Exhaust system: | Catalyst exhaust system | | Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 8.00 litres (2.11 gallons) | | Color options: | Silver, royal blue, dark blue, tTitanium | | Further information |
|---|
