KTM 85 SX 17-14 2012

Picture credits - KTM. Click to submit more pictures.

2012 KTM 85 SX 17-14

Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale

Tip a friend
List related bikes

KTM's profilation of this bike

The 85 SX masters the toughest MX tracks with unperturbed ease. The grown-up KTM mini-crosser combines fully-fledged MX technology with perfect controllability.

General information
Model:	KTM 85 SX 17-14
Year:	2012
Category:	Minibike, cross
Rating:	68.1 out of 100. Show full rating and compare with other bikes
Engine and transmission
Displacement:	84.90 ccm (5.18 cubic inches)
Engine type:	Single cylinder, two-stroke
Bore x stroke:	47.0 x 49.0 mm (1.9 x 1.9 inches)
Fuel system:	Carburettor. Keihin PWK 28
Ignition:	Moric digital 2M1
Lubrication system:	Mixture oil lubrication 1:40
Cooling system:	Liquid
Gearbox:	6-speed
Transmission type, final drive:	Chain
Clutch:	Wet mDouble disk clutch, operated hydraulically
Chassis, suspension, brakes and wheels
Frame type:	Double grinded central double-cradle-type frame. Subframe: Aluminium.
Rake (fork angle):	24.0°
Front suspension:	WP USD 43 mm (1.69 in)
Front suspension travel:	185 mm (7.3 inches)
Rear suspension:	WP PDS mono shock
Rear suspension travel:	185 mm (7.3 inches)
Front tyre dimensions:	70/100-17
Rear tyre dimensions:	90/100-14
Front brakes:	Single disc
Front brakes diameter:	220 mm (8.7 inches)
Rear brakes:	Single disc
Rear brakes diameter:	210 mm (8.3 inches)
Wheels:	1.4 x 17in., 1.6 x 14in. Alu
Physical measures and capacities
Dry weight:	66.0 kg (145.5 pounds)
Seat height:	845 mm (33.3 inches) If adjustable, lowest setting.
Wheelbase:	1,290 mm (50.8 inches)
Fuel capacity:	5.00 litres (1.32 gallons)
Other specifications
Starter:	Kick
Color options:	Orange/black/white
Further information
Parts and accessories	Check out parts and accessories from our other partners.
Ask questions	Join the 12 KTM 85 SX 17-14 discussion group.
Insurance, loans, tests	Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc.
Related bikes	List related bikes for comparison of specs

Free motorcycle classifieds

Click here to sell a used 2012 KTM 85 SX 17-14 or advertise any other MC for sale. You can list all available KTM 85 SX 17-14 bikes and also sign up for e-mail notification when such motorcycles are advertised in the future. Ads with or without pictures are easy to create. Our classifieds are completely free with sections for every country in the world.

You can also check out our list of related motorbikes. Compare technical data. Look at photos. View your fellow riders' rating of the bike's reliability, design, engine performance, accident risk, repair cost, etc.

Rating sample for this KTM bike
Racing track capabilities for the 2012 KTM 85 SX 17-14: (72.1 out of 100) Click here for complete rating. You can also compare bikes.
