KTM 450 XC 20122012 KTM 450 XC specifications, pictures, reviews and rating |
2012 KTM 450 XC. Picture credits - KTM. Submit more pictures. |
|
KTM's profilation of this bike |
Minimum weight, maximum power, perfect handling and peak performance in the hardest of races – these are properties which distinguish a real cross country champion. The KTM 450 XC has been developed for precisely this field and is aimed 100% at a single goal: podium places! |
General information | |
---|---|
Model name | KTM 450 XC |
Year | 2012 |
Category | ATV |
Rating |
Do you know this bike? Click here to rate it. We miss 2 votes to show the rating. |
Engine and transmission | |
Displacement | 447.9 ccm (27.33 cubic inches) |
Engine type | Single cylinder, four-stroke |
Engine details | OHC with roller rocker lever |
Compression | 11.0:1 |
Bore x stroke | 89.0 x 72.0 mm (3.5 x 2.8 inches) |
Valves per cylinder | 4 |
Fuel system | Carburettor. Keihin MX FCR 39 |
Fuel control | Single Overhead Cams (SOHC) |
Ignition | Kokusan digital 4K-3B |
Lubrication system | Pressure lubrication with 2 Eaton pumps |
Cooling system | Liquid |
Gearbox | 5-speed |
Clutch | Wet multi-disc clutch, operated hydraulically |
Driveline | 14:38 |
Exhaust system | Aluminum XC w/Spark Arrestor |
Chassis, suspension, brakes and wheels | |
Frame type | Chromoly (25 CrMo4). Subframe: Aluminum. |
Front suspension | Ohlins fully adjustable, Twin Chromoly A-arms |
Front wheel travel | 275 mm (10.8 inches) |
Rear suspension | Ohlins PDS Mono-shock, Fully Adjustable, Chromoly Swingarm |
Rear wheel travel | 272 mm (10.7 inches) |
Front tire | 21/7-10 |
Rear tire | 20/11-9 |
Front brakes | Single disc. Floating Wave discs, 4-piston fixed caliper |
Diameter | 180 mm (7.1 inches) |
Rear brakes | Single disc. Single piston floating caliper |
Diameter | 200 mm (7.9 inches) |
Wheels | 5.0 inches X 10.0 inches DWT Al 6061/ 8.0 inches X 9.0 inches DWT Al 6061; |
Physical measures and capacities | |
Dry weight | 163.0 kg (359.4 pounds) |
Seat height | 820 mm (32.3 inches) If adjustable, lowest setting. |
Ground clearance | 290 mm (11.4 inches) |
Wheelbase | 1280 mm (50.4 inches) |
Fuel capacity | 13.40 litres (3.54 US gallons) |
Other specifications | |
Color options | Orange/black |
Starter | Electric & kick |
