| General information |
|---|
| Model: | KTM 450 XC |
| Year: | 2012 |
| Category: | ATV |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 447.92 ccm (27.33 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Engine details: | OHC with roller rocker lever |
| Compression: | 11.0:1 |
| Bore x stroke: | 89.0 x 72.0 mm (3.5 x 2.8 inches) |
| Valves per cylinder: | 4 |
| Fuel system: | Carburettor. Keihin MX FCR 39 |
| Fuel control: | SOHC |
| Ignition: | Kokusan digital 4K-3B |
| Lubrication system: | Pressure lubrication with 2 Eaton pumps |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
| Clutch: | Wet multi-disc clutch, operated hydraulically |
| Driveline: | 14:38 |
| Exhaust system: | Aluminum XC w/Spark Arrestor |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Chromoly (25 CrMo4). Subframe: Aluminum. |
| Front suspension: | Ohlins fully adjustable, Twin Chromoly A-arms |
| Front suspension travel: | 275 mm (10.8 inches) |
| Rear suspension: | Ohlins PDS Mono-shock, Fully Adjustable, Chromoly Swingarm |
| Rear suspension travel: | 272 mm (10.7 inches) |
| Front tyre dimensions: | 21/7-10 |
| Rear tyre dimensions: | 20/11-9 |
| Front brakes: | Single disc. Floating Wave discs, 4-piston fixed caliper |
| Front brakes diameter: | 180 mm (7.1 inches) |
| Rear brakes: | Single disc. Single piston floating caliper |
| Rear brakes diameter: | 200 mm (7.9 inches) |
| Wheels: | 5.0 inches X 10.0 inches DWT Al 6061/ 8.0 inches X 9.0 inches DWT Al 6061; |
| Physical measures and capacities |
|---|
| Dry weight: | 163.0 kg (359.4 pounds) |
| Seat height: | 820 mm (32.3 inches) If adjustable, lowest setting. |
| Ground clearance: | 290 mm (11.4 inches) |
| Wheelbase: | 1,280 mm (50.4 inches) |
| Fuel capacity: | 13.40 litres (3.54 gallons) |
| Other specifications |
|---|
| Starter: | Electric & kick |
| Color options: | Orange/black |
