| KTM's profilation of this bike |
| Not a bike but a racing machine which is the main contender on all tracks. As well as the revolutionary engine, this bike also has an extremely light chassis and trend-setting running gear. For 2009, the 450 SX-F (like the 250 SX-F) has been trimmed at the factory specifically for MX1 series wins: with huge numbers of great PowerParts! |
| General information |
|---|
| Model: | KTM 450 SX-F | | Year: | 2009 | | Category: | Enduro / offroad | | Rating: | 75.6 out of 100. Show full rating and compare with other bikes | | Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 449.30 ccm (27.42 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 4 | | Compression: | 12.5:1 | | Bore x stroke: | 97.0 x 60.8 mm (3.8 x 2.4 inches) | | Fuel system: | Carburettor. Keihin MX FCR 41 | | Valves per cylinder: | 4 | | Fuel control: | DOHC | | Ignition: | Kokusan digital DC-CDI | | Starter: | Electric | | Lubrication system: | Pressure lubrication | | Cooling system: | Liquid | | Gearbox: | 4-speed | Transmission type
final drive: | Chain | | Clutch: | Wet multi-disc clutch, operated hydraulically | | Physical measures |
|---|
| Dry weight: | 104.6 kg (230.6 pounds) | | Seat height: | 985 mm (38.8 inches) If adjustable, lowest setting. | | Ground clearance: | 380 mm (15.0 inches) | | Wheelbase: | 1,475 mm (58.1 inches) | | Chassis and dimensions |
|---|
| Frame type: | Central double-cradle-type 25 CrMo4. Aluminium subframe. | | Rake (fork angle): | 26.5° | | Front suspension: | WP USD | | Front suspension travel: | 300 mm (11.8 inches) | | Rear suspension: | WP PDS shock absorber | | Rear suspension travel: | 335 mm (13.2 inches) | | Front tyre dimensions: | 80/100-21 | | Rear tyre dimensions: | 110/90-19 | | Front brakes: | Single disc | | Front brakes diameter: | 260 mm (10.2 inches) | | Rear brakes: | Single disc | | Rear brakes diameter: | 220 mm (8.7 inches) | | Exhaust system: | Aluminium | | Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 8.00 litres (2.11 gallons) | | Color options: | Orange | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our partners.  |
| Ask questions | Join the 09 KTM 450 SX-F discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
