| General information |
|---|
| Model: | KTM 250 SX-F |
| Year: | 2007 |
| Category: | Cross / motocross |
| Rating: | 71.7 out of 100. Show full rating and compare with other bikes |
| Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 249.50 ccm (15.22 cubic inches) |
| Engine type: | Single cylinder |
| Stroke: | 4 |
| Compression: | 12.8:1 |
| Bore x stroke: | 76.0 x 55.0 mm (3.0 x 2.2 inches) |
| Fuel system: | Carburettor. Keihin MX FCR 39 |
| Valves per cylinder: | 4 |
| Fuel control: | DOHC |
| Ignition: | Kokusan digital 4K-3A |
| Starter: | Kick |
| Lubrication system: | Pressure lubrication with 2 Eaton pumps |
| Cooling system: | Liquid |
| Gearbox: | 6-speed |
Transmission type
final drive: | Chain |
| Clutch: | Wet multi-disc clutch, operated hydraulically |
| Physical measures |
|---|
| Dry weight: | 98.5 kg (217.2 pounds) |
| Seat height: | 925 mm (36.4 inches) If adjustable, lowest setting. |
| Ground clearance: | 380 mm (15.0 inches) |
| Wheelbase: | 1,481 mm (58.3 inches) |
| Chassis and dimensions |
|---|
| Frame type: | Central double-cradle-type 25CrMo4 |
| Rake (fork angle): | 26.5° |
| Front suspension: | WP USD |
| Front suspension travel: | 115 mm (4.5 inches) |
| Rear suspension: | WP monoshock PDS |
| Rear suspension travel: | 185 mm (7.3 inches) |
| Front tyre dimensions: | 80/100-21 |
| Rear tyre dimensions: | 100/90-19 |
| Front brakes: | Single disc |
| Rear brakes: | Single disc |
| Exhaust system: | Aluminium |
| Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 7.00 litres (1.85 gallons) |
