| Keeway's profilation of this bike |
| Hidden inside this smooth engine is pleasantly surprising power. ARN offers superb versatility with smart, sporty aesthetics. |
| General information |
|---|
| Model: | Keeway ARN 125 | | Year: | 2009 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 124.60 ccm (7.60 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 4 | | Power: | 8.31 HP (6.1 kW)) @ 7500 RPM | | Torque: | 7.80 Nm (0.8 kgf-m or 5.8 ft.lbs) @ 6500 RPM | | Compression: | 9.5:1 | | Bore x stroke: | 52.4 x 57.8 mm (2.1 x 2.3 inches) | | Fuel system: | Carburettor | | Fuel control: | OHC | | Ignition: | C.D.I. | | Starter: | Electric & kick | | Cooling system: | Air | Transmission type
final drive: | Belt | | Clutch: | Dry, centrifugal | | Physical measures |
|---|
| Dry weight: | 105.0 kg (231.5 pounds) | | Overall length: | 1,920 mm (75.6 inches) | | Overall width: | 700 mm (27.6 inches) | | Wheelbase: | 1,300 mm (51.2 inches) | | Chassis and dimensions |
|---|
| Front tyre dimensions: | 120/70-12 | | Rear tyre dimensions: | 130/70-12 | | Front brakes: | Single disc | | Rear brakes: | Expanding brake (drum brake) | | Speed and acceleration |
|---|
| Top speed: | 82.0 km/h (51.0 mph) | | Power/weight ratio: | 0.0791 HP/kg | | Other specifications |
|---|
| Fuel capacity: | 5.00 litres (1.32 gallons) | | Fuel consumption pr. 10 km (6.2 miles): | 2.60 litres (0.69 gallons) | | Further information |
|---|
