| Husqvarna's profilation of this bike |
| The all new CR 50 represents the pinnacle of Husqvarna’s proven off road product development with the use of quality materials and components that in turn offer a standard equipment level that is sure to become the benchmark for the category. |
| General moped information |
|---|
| Model: | Husqvarna CR50 | | Year: | 2012 | | Category: | Minibike, cross | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Engine and transmission |
|---|
| Displacement: | 49.00 ccm (2.99 cubic inches) | | Engine type: | Single cylinder, two-stroke | | Compression: | 7.1:1 | | Bore x stroke: | 39.5 x 40.0 mm (1.6 x 1.6 inches) | | Fuel system: | Carburettor. Dell´Orto PHBG 19 | | Ignition: | Electronic C.D.I. | | Lubrication system: | Premix 50 : 1 | | Cooling system: | Liquid | | Gearbox: | 1-speed | Transmission type,
final drive: | Chain | | Clutch: | Dry, centrifugal type | | Driveline: | Single speed, chain final drive | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel single tube, steel rear frame | | Front suspension: | Marzocchi conventional telescopic hydraulic fork with advanced axle | | Front suspension travel: | 200 mm (7.9 inches) | | Rear suspension: | Sachs Progressive Soft Damp type with single hydraulic shock absorber, spring pre-load adjustment | | Rear suspension travel: | 200 mm (7.9 inches) | | Front tyre dimensions: | 60/100-12 | | Rear tyre dimensions: | 2.75-10 | | Front brakes: | Single disc | | Front brakes diameter: | 160 mm (6.3 inches) | | Rear brakes: | Single disc | | Rear brakes diameter: | 140 mm (5.5 inches) | | Physical measures and capacities |
|---|
| Dry weight: | 43.4 kg (95.7 pounds) | | Seat height: | 680 mm (26.8 inches) If adjustable, lowest setting. | | Overall height: | 880 mm (34.6 inches) | | Overall length: | 1,400 mm (55.1 inches) | | Overall width: | 655 mm (25.8 inches) | | Ground clearance: | 250 mm (9.8 inches) | | Wheelbase: | 995 mm (39.2 inches) | | Fuel capacity: | 2.70 litres (0.71 gallons) | | Other specifications |
|---|
| Starter: | Kick | | Color options: | Red/White | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 12 Husqvarna CR50 discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
