| Honda's profilation of this bike |
| Relentless. Tireless. Tenacious. There are plenty of things you can say about the Honda TRX400X, but to fully understand it, you have to experience it. That’s because underneath the race-style bodywork lies everything the warrior ATV rider needs, starting with the SOHC, 397cc, air-cooled, dry-sump RFVD engine. Then there’s the triple-disc brakes. |
| General information |
|---|
| Model: | Honda TRX400X | | Year: | 2012 | | Category: | ATV | | Rating: | 78.7 out of 100. Show full rating and compare with other bikes | | Price as new (MSRP): | US$ 6299. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 397.00 ccm (24.22 cubic inches) | | Engine type: | Single cylinder, four-stroke | | Compression: | 12.0:1 | | Bore x stroke: | 85.0 x 70.0 mm (3.3 x 2.8 inches) | | Ignition: | CD with electronic advance | | Lubrication system: | Dry sump | | Cooling system: | Air | | Gearbox: | 5-speed | Transmission type,
final drive: | Chain | | Clutch: | Manual | | Driveline: | O-ring-sealed chain | | Emission details: | Meets current California Air Resources Board (CARB) off-road emissions standards. | | Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Independent double-wishbone with Showa shocks, five-position spring preload adjustability | | Front suspension travel: | 208 mm (8.2 inches) | | Rear suspension: | Pro-Link fully adjustable single Showa shock | | Rear suspension travel: | 231 mm (9.1 inches) | | Front tyre dimensions: | 22/7-10 | | Rear tyre dimensions: | 20/10-9 | | Front brakes: | Double disc | | Front brakes diameter: | 174 mm (6.9 inches) | | Rear brakes: | Single disc | | Rear brakes diameter: | 220 mm (8.7 inches) | | Physical measures and capacities |
|---|
| Weight incl. oil, gas, etc: | 185.1 kg (408.0 pounds) | | Seat height: | 836 mm (32.9 inches) If adjustable, lowest setting. | | Overall height: | 1,118 mm (44.0 inches) | | Overall length: | 1,821 mm (71.7 inches) | | Overall width: | 1,156 mm (45.5 inches) | | Ground clearance: | 104 mm (4.1 inches) | | Wheelbase: | 1,217 mm (47.9 inches) | | Fuel capacity: | 9.84 litres (2.60 gallons) | | Reserve fuel capacity: | 1.51 litres (0.40 gallons) | | Other specifications |
|---|
| Factory warranty: | One year | | Color options: | Black/Red | | Comments: | Model ID: TRX400X | | Further information |
|---|
| Parts and accessories | Our partner CMSNL
ships low cost OEM motorcycle parts to
Australia, Austria, Bahamas, Belgium, Canada, China, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany,
Greece, Hong Kong, Hungary, Iceland, India, Ireland, Italy, Japan, Kuwait, Latvia, Lithuania, Luxembourg, Macedonia, Malta, Montenegro,
The Netherlands, New Zealand, Norway, Poland, Portugal, Serbia, Slovakia, Slovenia, South Africa, Spain, Sweden, Switzerland,
Taiwan, Ukraine, United Kingdom, The United States and more. Or check out parts and accessories from our other partners. |
| Ask questions | Join the 12 Honda TRX400X discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
