| Honda's profilation of this bike |
| The perfect blend of performance: dependable 223cc engine, a wide, four-stroke powerband, great suspension and electric start — packaged in a bike geared toward family fun.
|
| General information |
|---|
| Model: | Honda CRF 230 F | | Year: | 2005 | | Category: | Enduro / offroad | | Rating: | 76.9 out of 100. Show full rating and compare with other bikes | | Engine and transmission |
|---|
| Displacement: | 223.00 ccm (13.61 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 4 | | Compression: | 9.0:1 | | Bore x stroke: | 65.5 x 66.2 mm (2.6 x 2.6 inches) | | Fuel control: | SOHC | | Ignition: | CDI | | Cooling system: | Air | | Gearbox: | 6-speed | Transmission type
final drive: | Chain | | More details | Consult a Honda repair manual. | | Physical measures |
|---|
| Dry weight: | 108.0 kg (238.0 pounds) | | Seat height: | 866 mm (34.1 inches) If adjustable, lowest setting. | | Ground clearance: | 297 mm (11.7 inches) | | Wheelbase: | 1,374 mm (54.1 inches) | | Chassis and dimensions |
|---|
| Rake (fork angle): | 27.3° | | Trail: | 112 mm (4.4 inches) | | Front suspension: | 37mm leading-axle Showa fork | | Front suspension travel: | 241 mm (9.5 inches) | | Rear suspension: | Pro-Link Showa single-shock with spring-preload adjustability | | Rear suspension travel: | 229 mm (9.0 inches) | | Front tyre dimensions: | 80/70-21 | | Rear tyre dimensions: | 100/90-18 | | Front brakes: | Single disc | | Front brakes diameter: | 240 mm (9.4 inches) | | Rear brakes: | Expanding brake (drum brake) | | Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 8.32 litres (2.20 gallons) | | Color options: | Red | | Comments: | Model ID: CRF230F | | Further information |
|---|
