13 Harley-Davidson Sportster Forty-Eight Dark Custom specificationsHarley-Davidson Sportster Forty-Eight Dark Custom 2013


2013 Harley-Davidson Sportster Forty-Eight Dark Custom photo
Picture credits - Harley-Davidson. Click to submit more pictures.
   Show big 2013 Harley-Davidson Sportster Forty-Eight Dark Custom imageShow more 2013 Harley-Davidson Sportster Forty-Eight Dark Custom images
2013 Harley-Davidson Sportster Forty-Eight Dark Custom

More pictures...

Discuss this bike
Rate this motorbike
This bike's rating
Write a review

Sell this motorcycle
Such bikes for sale

Tip a friend
List related bikes



Harley-Davidson's profilation of this bike
When the look is fast and smooth, details count and clutter doesn’t make the cut. We carefully crafted the rear end with retro-styled Stop-Turn-Tail lights to leave the fender surface clean and uncluttered for an authentically raw, custom look. And while the lamps may look old-school, it´s their new-school engineering that keeps things clean, packing stop, turn and running beams into each bullet.

General information
Model:Harley-Davidson Sportster Forty-Eight Dark Custom
Year:2013
Category:Custom / cruiser
Rating:Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating.
Price as new (MSRP):US$ 10599. Prices depend on country, taxes, accessories, etc.
Engine and transmission
Displacement:1201.25 ccm (73.30 cubic inches)
Engine type:V2, four-stroke
Engine details:Air-cooled, Evolution®
Torque:107.12 Nm (10.9 kgf-m or 79.0 ft.lbs) @ 4000 RPM
Compression:9.7:1
Bore x stroke:88.9 x 96.8 mm (3.5 x 3.8 inches)
Fuel system:Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Cooling system:Air
Gearbox:6-speed
Transmission type,
final drive:
Belt
Driveline:Chain, 57/38 ratio primary drive
Fuel consumption:4.90 litres/100 km (20.4 km/l or 48.00 mpg)
Greenhouse gases:113.7 CO2 g/km. (CO2 - Carbon dioxide emission)
Exhaust system:Chrome, staggered shorty exhaust with dual slash-cut mufflers
Chassis, suspension, brakes and wheels
Rake (fork angle):30.0°
Trail:107 mm (4.2 inches)
Front tyre dimensions:130/90-B16
Rear tyre dimensions:150/80-B16
Front brakes:Single disc. Dual-piston
Rear brakes:Single disc. Single-piston
Wheels:Black, Laced Steel
Physical measures and capacities
Dry weight:250.8 kg (553.0 pounds)
Weight incl. oil, gas, etc:259.9 kg (573.0 pounds)
Seat height:660 mm (26.0 inches) If adjustable, lowest setting.
Overall length:2,250 mm (88.6 inches)
Wheelbase:1,519 mm (59.8 inches)
Fuel capacity:7.95 litres (2.10 gallons)
Oil capacity:2.60 litres (0.17 quarts)
Other specifications
Starter:Electric
Instruments:4-inch Speedometer mounted low and integrated into handlebar clamp electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, LED indicator lights
Light:High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
Color options:Black
