| Harley-Davidson's profilation of this bike |
| The ultimate wide-shouldered cruiser, now featuring optional H-D1™ Factory Customization. |
| General information |
|---|
| Model: | Harley-Davidson Sporster 1200 Custom | | Year: | 2013 | | Category: | Custom / cruiser | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Price as new (MSRP): | US$ 10499. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 1201.25 ccm (73.30 cubic inches) | | Engine type: | V2, four-stroke | | Engine details: | Air-cooled, Evolution® | | Torque: | 107.12 Nm (10.9 kgf-m or 79.0 ft.lbs) @ 3250 RPM | | Compression: | 9.7:1 | | Bore x stroke: | 88.9 x 96.8 mm (3.5 x 3.8 inches) | | Fuel system: | Injection. Electronic Sequential Port Fuel Injection (ESPFI) | | Lubrication system: | Dry sump | | Cooling system: | Air | | Gearbox: | 6-speed | Transmission type,
final drive: | Belt | | Clutch: | Multi-plate with diaphragm spring in oil bath | | Fuel consumption: | 4.90 litres/100 km (20.4 km/l or 48.00 mpg) | | Greenhouse gases: | 113.7 CO2 g/km. (CO2 - Carbon dioxide emission) | | Exhaust system: | Chrome, staggered exhaust with slash-cut mufflers | | Chassis, suspension, brakes and wheels |
|---|
| Rake (fork angle): | 29.9° | | Trail: | 60 mm (2.4 inches) | | Front tyre dimensions: | 130/90-B16 | | Rear tyre dimensions: | 150/80-B16 | | Front brakes: | Single disc | | Rear brakes: | Single disc | | Wheels: | Chrome, 5-Spoke Cast Aluminum | | Physical measures and capacities |
|---|
| Dry weight: | 250.8 kg (553.0 pounds) | | Weight incl. oil, gas, etc: | 259.9 kg (573.0 pounds) | | Seat height: | 676 mm (26.6 inches) If adjustable, lowest setting. | | Overall length: | 2,220 mm (87.4 inches) | | Ground clearance: | 112 mm (4.4 inches) | | Wheelbase: | 1,521 mm (59.9 inches) | | Fuel capacity: | 2.80 litres (0.74 gallons) | | Oil capacity: | 2.60 litres (0.17 quarts) | | Other specifications |
|---|
| Starter: | Electric | | Instruments: | Handlebar-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights | | Light: | High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional) | | Color options: | Anniversary Vintage Bronze/Anniversary Vintage Black, Candy Orange/Beer Bottle, Ember Red Sunglo, Big Blue Pearl, Vivid Black, custom colors | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 13 Harley-Davidson Sporster 1200 Custom discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
