| General information |
|---|
| Model: | Derbi Sonar 125 4T |
| Year: | 2011 |
| Category: | Scooter |
| Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. |
| Price as new (MSRP): | Euro 1882. Prices depend on country, taxes, accessories, etc. |
| Engine and transmission |
|---|
| Displacement: | 124.00 ccm (7.57 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 10.60 HP (7.7 kW)) @ 8000 RPM |
| Torque: | 9.60 Nm (1.0 kgf-m or 7.1 ft.lbs) @ 7250 RPM |
| Compression: | 10.6:1 |
| Bore x stroke: | 57.0 x 48.6 mm (2.2 x 1.9 inches) |
| Fuel system: | Carburettor |
| Lubrication system: | Mechanical oil pump |
| Cooling system: | Air |
| Gearbox: | Automatic |
Transmission type,
final drive: | Belt |
| Clutch: | Automatic centrifugal |
| Emission details: | Compartment underthe seat to hold a jet helmet. |
| Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | 32 mm fork. |
| Front suspension travel: | 76 mm (3.0 inches) |
| Rear suspension: | Monoshock |
| Rear suspension travel: | 64 mm (2.5 inches) |
| Front tyre dimensions: | 90/80-16 |
| Rear tyre dimensions: | 110/80-14 |
| Front brakes: | Single disc |
| Front brakes diameter: | 220 mm (8.7 inches) |
| Rear brakes: | Expanding brake (drum brake) |
| Rear brakes diameter: | 140 mm (5.5 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 99.0 kg (218.3 pounds) |
| Power/weight ratio: | 0.1071 HP/kg |
| Seat height: | 805 mm (31.7 inches) If adjustable, lowest setting. |
| Overall length: | 1,930 mm (76.0 inches) |
| Overall width: | 740 mm (29.1 inches) |
| Wheelbase: | 1,325 mm (52.2 inches) |
| Fuel capacity: | 6.00 litres (1.59 gallons) |
| Other specifications |
|---|
| Starter: | Electric |
| Color options: | White, red, black |
| Comments: | Spanish scooter. |
