| Cectek's profilation of this bike |
| Low center of gravity, powerful and reliable Electronics Fuel Injection 500 cc liquid cooled engine. |
| General information |
|---|
| Model: | Cectek Quadrift 500 EFI | | Year: | 2011 | | Category: | ATV | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Engine and transmission |
|---|
| Displacement: | 500.00 ccm (30.51 cubic inches) | | Engine type: | Single cylinder, four-stroke | | Fuel system: | Injection. Electronic Fuel Injection (EFI) | | Cooling system: | Liquid | | Gearbox: | Automatic | Transmission type,
final drive: | Belt | | Clutch: | Non-centrifugal clutch CVT system with engine braking function | | Chassis, suspension, brakes and wheels |
|---|
| Front suspension: | Independent, double A-arm, continuous preload seetings, | | Front suspension travel: | 102 mm (4.0 inches) | | Rear suspension: | Independent, double A-arm, oil-damped, continuous preload settings, sway-bar | | Rear suspension travel: | 102 mm (4.0 inches) | | Front tyre dimensions: | 195/45-R15 | | Rear tyre dimensions: | 215/40-R16 | | Front brakes: | Double disc | | Front brakes diameter: | 250 mm (9.8 inches) | | Rear brakes: | Single disc | | Wheels: | Aluminum wheels and low-profile highway tire | | Physical measures and capacities |
|---|
| Dry weight: | 310.0 kg (683.4 pounds) | | Seat height: | 776 mm (30.6 inches) If adjustable, lowest setting. | | Overall height: | 1,101 mm (43.3 inches) | | Overall length: | 2,158 mm (85.0 inches) | | Overall width: | 1,310 mm (51.6 inches) | | Ground clearance: | 137 mm (5.4 inches) | | Wheelbase: | 1,280 mm (50.4 inches) | | Fuel capacity: | 19.00 litres (5.02 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Instruments: | Multifunction LCD display. RPM/Speed/ODO/Trip/Time/Fuel Water Temp/Oil pressure/Back Light:Orange Indicator/Shift Position/High beam/Flash/Engine over speed/Diff. locked. | | Carrying capacity: | 60kg rear rack. 425 kg towing capacity. | | Color options: | Gray, silver, white, green | | Comments: | Integrated gearbox inside the engine with Park, Neuter, Hi-Lo dual range and Reverse Gears. | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 11 Cectek Quadrift 500 EFI discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
