| General information |
|---|
| Model: | BMW F 650 CS |
| Year: | 2004 |
| Category: | Allround |
| Rating: | 69.9 out of 100. Show full rating and compare with other bikes |
| Engine and transmission |
|---|
| Displacement: | 652.00 ccm (39.79 cubic inches) |
| Engine type: | Single cylinder |
| Stroke: | 4 |
| Power: | 50.00 HP (36.5 kW)) @ 6500 RPM |
| Torque: | 60.00 Nm (6.1 kgf-m or 44.3 ft.lbs) @ 4800 RPM |
| Compression: | 11.5:1 |
| Bore x stroke: | 100.0 x 83.0 mm (3.9 x 3.3 inches) |
| Fuel system: | Injection |
| Valves per cylinder: | 4 |
| Fuel control: | DOHC |
| Cooling system: | Liquid |
| Gearbox: | 5-speed |
Transmission type
final drive: | Chain |
| More details | Consult a BMW repair manual. |
| Physical measures |
|---|
| Dry weight: | 175.0 kg (385.8 pounds) |
| Seat height: | 750 mm (29.5 inches) If adjustable, lowest setting. |
| Alternate seat height: | 820 mm (32.3 inches) If adjustable, highest setting. |
| Overall height: | 910 mm (35.8 inches) |
| Overall length: | 2,175 mm (85.6 inches) |
| Overall width: | 1,265 mm (49.8 inches) |
| Wheelbase: | 1,479 mm (58.2 inches) |
| Chassis and dimensions |
|---|
| Frame type: | Bridge-type steel section frame with bolted-on rear section |
| Rake (fork angle): | 29.2° |
| Front suspension: | Telescopic fork, stanchion diameter 41 mm, fork stabiliser, 170 mm travel |
| Rear suspension: | Box-section steel section dual swing arm, central spring strut action via lever system, spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable, 165 mm travel |
| Front tyre dimensions: | 100/90-18 |
| Rear tyre dimensions: | 130/80-17 |
| Front brakes: | Single disc |
| Front brakes diameter: | 300 mm (11.8 inches) |
| Rear brakes: | Single disc |
| Rear brakes diameter: | 240 mm (9.4 inches) |
| Speed and acceleration |
|---|
| Power/weight ratio: | 0.2857 HP/kg |
| Other specifications |
|---|
| Fuel capacity: | 17.30 litres (4.57 gallons) |
| Reserve fuel capacity: | 4.50 litres (1.19 gallons) |
