| Big Dog's profilation of this bike |
| Performance and style redefined. |
| General information |
|---|
| Model: | Big Dog Wolf | | Year: | 2009 | | Category: | Custom / cruiser | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 1976.00 ccm (120.58 cubic inches) | | Engine type: | V2 | | Stroke: | 4 | | Compression: | 9.9:1 | | Bore x stroke: | 108.0 x 108.0 mm (4.3 x 4.3 inches) | | Fuel system: | Injection. EFI | | Fuel control: | OHV | | Starter: | Electric | | Cooling system: | Air | | Gearbox: | 6-speed | Transmission type
final drive: | Belt | | Physical measures |
|---|
| Dry weight: | 349.0 kg (769.4 pounds) | | Seat height: | 622 mm (24.5 inches) If adjustable, lowest setting. | | Overall length: | 2,604 mm (102.5 inches) | | Ground clearance: | 114 mm (4.5 inches) | | Wheelbase: | 1,969 mm (77.5 inches) | | Chassis and dimensions |
|---|
| Frame type: | Steel | | Rake (fork angle): | 40.0° | | Trail: | 148 mm (5.8 inches) | | Front suspension: | 41 mm Telescopic Sleeved | | Front tyre dimensions: | 130/760-R23 | | Rear tyre dimensions: | 220/50-R20 | | Front brakes: | Single disc. 4-piston diff bore | | Rear brakes: | Single disc. 4-piston drive side | | Speed and acceleration |
|---|
| Other specifications |
|---|
| Fuel capacity: | 17.00 litres (4.49 gallons) | | Reserve fuel capacity: | 2.64 litres (0.70 gallons) | | Oil capacity: | 2.80 litres (0.18 quarts) | | Comments: | X-Wedge engine | | Further information |
|---|
