| Big Bear Choppers' profilation of this bike |
| Chassis configuration includes a drop seat of 20” off the ground, a manageable wheelbase with a conservative 43° neck rake, foot and hand controls reaching towards the rider for a comfortable position, patented unique fuel tank design, patented oil tank design holding 5 quarts, 250mm rear tire with a right side final drive. |
| General information |
|---|
| Model: | Big Bear Choppers Rage 100 Smooth EFI | | Year: | 2010 | | Category: | Custom / cruiser | | Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. | | Price as new (MSRP): | US$ 31900. Prices depend on country, taxes, accessories, etc. | | Engine and transmission |
|---|
| Displacement: | 1638.81 ccm (100.00 cubic inches) | | Engine type: | V2, four-stroke | | Power: | 95.00 HP (69.3 kW)) | | Torque: | 151.87 Nm (15.5 kgf-m or 112.0 ft.lbs) | | Fuel system: | Injection. EFI | | Ignition: | Dynatech 2000i | | Lubrication system: | S and S High volume oil pump | | Gearbox: | 6-speed | Transmission type,
final drive: | Chain | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | BBC Rage Softail. BBC Venom swingarm. | | Rake (fork angle): | 43.0° | | Trail: | 95 mm (3.8 inches) | | Front suspension: | BBC Springer, powder coated. | | Rear suspension: | Progressive | | Front tyre dimensions: | 90/80-21 | | Rear tyre dimensions: | 250/80-18 | | Front brakes: | Single disc. P.M. 4-piston calipers | | Rear brakes: | Single disc. BBC-PM 4-piston caliper BrakeDrive system | | Physical measures and capacities |
|---|
| Dry weight: | 317.5 kg (700.0 pounds) | | Power/weight ratio: | 0.2992 HP/kg | | Seat height: | 508 mm (20.0 inches) If adjustable, lowest setting. | | Overall length: | 2,794 mm (110.0 inches) | | Wheelbase: | 2,083 mm (82.0 inches) | | Fuel capacity: | 14.19 litres (3.75 gallons) | | Oil capacity: | 5.00 litres (0.33 quarts) | | Other specifications |
|---|
| Starter: | Electric | | Color options: | Gross Black, satin black, charcoal metallic, silver metallic, black cherry, candy red, firecracker red, orange pearl, electric blue, pearl white or custom paint schemes. | | Comments: | Proprietary patented mid-section stretch in the frame for better weight distribution and handling. Distinctive large diameter single radius downtube. Standard neck height with a conservative 43° rake for an agile and well-coordinated movement. Baker right side drive. | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 10 Big Bear Choppers Rage 100 Smooth EFI discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
