| General information |
|---|
| Model: | Gilera Nexus 300 Simoncelli |
| Year: | 2009 |
| Category: | Scooter |
| Rating: | Do you know this bike?
Click here to rate it. We miss 1 vote to show the rating. |
| Engine and transmission |
|---|
| Displacement: | 292.00 ccm (17.82 cubic inches) |
| Engine type: | Single cylinder, four-stroke |
| Power: | 22.40 HP (16.4 kW)) @ 7250 RPM |
| Torque: | 23.00 Nm (2.3 kgf-m or 17.0 ft.lbs) @ 6000 RPM |
| Bore x stroke: | 75.0 x 63.0 mm (3.0 x 2.5 inches) |
| Fuel system: | Injection |
| Ignition: | Electronic inductive discharge |
| Cooling system: | Liquid |
| Gearbox: | Automatic |
Transmission type,
final drive: | Belt |
| Clutch: | Dry centrifugal type |
| Exhaust system: | Closed loop system with lambda sensor and three-way catalytic converter in exhaust pipe |
| Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Double cradle trellis made of high-strength steel tubes |
| Front suspension: | Telescopic hydraulic fork |
| Front suspension travel: | 94 mm (3.7 inches) |
| Rear suspension: | Double hydraulic shock absorber with four-position spring preload |
| Rear suspension travel: | 76 mm (3.0 inches) |
| Front tyre dimensions: | 120/70-15 |
| Rear tyre dimensions: | 140/60-14 |
| Front brakes: | Single disc. Stainless steel disk, two-piston floating caliper |
| Front brakes diameter: | 260 mm (10.2 inches) |
| Rear brakes: | Single disc. Stainless steel disk, caliper with two opposite pistons |
| Rear brakes diameter: | 240 mm (9.4 inches) |
| Physical measures and capacities |
|---|
| Dry weight: | 174.0 kg (383.6 pounds) |
| Power/weight ratio: | 0.1287 HP/kg |
| Seat height: | 815 mm (32.1 inches) If adjustable, lowest setting. |
| Overall length: | 2,100 mm (82.7 inches) |
| Overall width: | 780 mm (30.7 inches) |
| Wheelbase: | 1,530 mm (60.2 inches) |
| Fuel capacity: | 15.00 litres (3.96 gallons) |
| Other specifications |
|---|
| Color options: | Red, black, gray |
| Comments: | Limited edition named after Marco Simoncelli. |
