| General information |
|---|
| Model: | Arctic Cat 350 | | Year: | 2012 | | Category: | ATV | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Engine and transmission |
|---|
| Displacement: | 366.00 ccm (22.33 cubic inches) | | Engine type: | Single cylinder, four-stroke | | Bore x stroke: | 81.0 x 71.2 mm (3.2 x 2.8 inches) | | Valves per cylinder: | 4 | | Fuel system: | Carburettor | | Fuel control: | SOHC | | Cooling system: | Oil & air | | Gearbox: | Automatic | Transmission type,
final drive: | Belt | | Driveline: | 4WD. Automatic CVT with EBS, Hi/Lo Range and Reverse. | | Chassis, suspension, brakes and wheels |
|---|
| Frame type: | Steel | | Front suspension: | Double A-Arm. Fully Independent Suspension. | | Front suspension travel: | 178 mm (7.0 inches) | | Rear suspension: | Double A-Arm | | Rear suspension travel: | 178 mm (7.0 inches) | | Front tyre dimensions: | 24/8-12 | | Rear tyre dimensions: | 24/10-12 | | Front brakes: | Single disc. Hydraulic | | Rear brakes: | Single disc. Hydraulic | | Physical measures and capacities |
|---|
| Dry weight: | 267.0 kg (588.6 pounds) | | Overall height: | 1,168 mm (46.0 inches) | | Overall length: | 2,116 mm (83.3 inches) | | Overall width: | 1,130 mm (44.5 inches) | | Ground clearance: | 254 mm (10.0 inches) | | Wheelbase: | 1,219 mm (48.0 inches) | | Fuel capacity: | 16.30 litres (4.31 gallons) | | Other specifications |
|---|
| Starter: | Electric | | Instruments: | Digital | | Electrical: | 12V 18 amps alternator. | | Carrying capacity: | Front Rack Capacity 75 lbs / 34 kg. Rear Rack Capacity 150 lbs / 68.1 kg. Towing Capacity 1,050 lbs / 476.3 kg | | Color options: | Red, Black | | Further information |
|---|
| Parts and accessories | Check out parts and accessories from our other partners. |
| Ask questions | Join the 12 Arctic Cat 350 discussion group. |
| Insurance, loans, tests
| Check out insurance here. Search the web for dealers, loan costs, tests, customizing, etc. |
| Related bikes | List related bikes for comparison of specs |
