| General moped information |
|---|
| Model: | Adly Noble 50 | | Year: | 2009 | | Category: | Scooter | | Rating: | Do you know this bike?
Click here to rate it. We miss 2 votes to show the rating. | | Safety: | See our safety campaign with the high safety rated bikes in this category.
|
| Engine and transmission |
|---|
| Displacement: | 49.26 ccm (3.01 cubic inches) | | Engine type: | Single cylinder | | Stroke: | 2 | | Power: | 3.67 HP (2.7 kW)) @ 5500 RPM | | Torque: | 4.75 Nm (0.5 kgf-m or 3.5 ft.lbs) @ 5500 RPM | | Compression: | 7.2:1 | | Fuel system: | Carburettor | | Fuel control: | SOHC | | Ignition: | C.D.I. | | Starter: | Electric & kick | | Cooling system: | Air | | Gearbox: | Automatic | Transmission type
final drive: | Belt | | Physical measures |
|---|
| Dry weight: | 77.0 kg (169.8 pounds) | | Overall height: | 1,160 mm (45.7 inches) | | Overall length: | 1,780 mm (70.1 inches) | | Overall width: | 675 mm (26.6 inches) | | Wheelbase: | 1,250 mm (49.2 inches) | | Chassis and dimensions |
|---|
| Front suspension: | Grease shock absorber | | Rear suspension: | Hydraulic shock absorber | | Front tyre dimensions: | 120/70-12 | | Rear tyre dimensions: | 130/60-13 | | Front brakes: | Single disc | | Rear brakes: | Expanding brake (drum brake) | | Speed and acceleration |
|---|
| Top speed: | 62.0 km/h (38.5 mph) | | Power/weight ratio: | 0.0477 HP/kg | | Other specifications |
|---|
| Color options: | Silver | | Comments: | Made in Taiwan. | | Further information |
|---|
